The '97' repeater is based on a Kenwood TKR-750 commercial repeater.
Most commercial two-way in the US have 150 MHz as the low end of their alignment.
That is because the commercial band normally runs from 150-170 MHz.
This equipment was designed for the ''low cut'' which includes the 2-meter band.
That allowed this commercial Kenwood TKR-750 to be optimally tuned to 146.970 Mhz.
These repeaters were designed for an output power of 50 Watts intermittent and 25 Watts continuous duty.
The ''97'' reapeter is operating at the recommended output of 25 watts in order to provide
extended life, reliability, and longer periods of continuous emergency operation.
The repeater Xmtr output is connected to a TxRx brand 4-cavity duplexer that was recently purchased by the club.
This TxRx duplexer has a specified loss of 1.5 db and provides more than 85 db of isolation.
The transmission line is 7/8 inch Andrew.
The antenna is a DB-224 which is a 4-element folded dipole array in omni configuration.
This antenna sits atop a 330' tower located near Waterbury Nebraska.
The base of the tower is at an elevation of 1500 feet above sea level.
With consideration for all losses in the transmission pathway the system is
producing a nominal RF power output
of somewhere between 12 and fifteen watts.
FYI:
Although the repeater's location is in Nebraska the assigned access tone for KØTFT Sioux City ''37/97'' repeater is 110.9 hz.
